Absima ATC2 4BL Electric R /C Touring Car 1 /10 4WD Brushless RTR Maximize

Absima ATC2 4BL Electric R /C Touring Car 1 /10 4WD Brushless RTR

Absima ATC2 4BL Electric R /C Touring Car 1 /10 4WD Brushless RTR

More details

p 12213

Add to cart

You can purchase this product in installments with Consel. Click here for more information.


touring car ATC2 4BL brushless rtr 1
Highlights & Details:
  • +60km/h · 4WD
  • Water-resistant brushless speed controller
  • 3421KV brushless motor
  • Pre-printed race body

Features:

  • Ready assembled
  • Water-resistant 50A brushless speed controller
  • 2.4 GHz radio system "CR2S"
  • 4 kg steering servo
  • 4WD
  • Complete ball bearing
  • Aluminum adjustable oil shocks
  • 2 gear differentials
  • 3421KV brushless motor
  • Aluminum chassis stiffener
  • Steel shafts - front/rear
  • Full adjustable chassis
  • Aluminum motor mount
  • Aluminum drive shaft
  • Pre-printed body
  • Steel transmission (spur gear and pinion gear)

touring car ATC2 4BL brushless rtr 2

Technical specifications:

  • Measure: ( L/W/H) 450x190x140 mm
  • Weight: 1425g
  • Radstand 260 mm
  • Chassis clearance: 20 mm
  • Front track 170 mm / Rear track 170 mm
  • Tires: Ø ±  65 mm / Width 27mm front/rear
  • Chassis: ATC
  • Viskosity Shock Oil:  300CPS f/r
  • Shock Size: front 62mm / rear 62mm
  • Internal transmission: 13T / 38T
  • Motor transmission: Spur gear 64T / Pinion gear 29T (Module 0.6)

touring car ATC2 4BL brushless rtr 3

Technical specification speed controller Thrust:
  • Water resistant 50A controller incl. cooler
  • 3S LiPo suitable
  • T-plug battery connector
  • Gold-bonded motor connector 3.5mm
  • Easy calibration and programming
  • Sensorless
  • NiMH 4 - 9 cells / LiPo 2 - 3 cells
  • Overheat protection: 95°
  • Peak amps: 300A
  • BEC 6V / 3A
  • Operating voltage 4.8 – 11.1V
  • Motor timing  18.75 deg.
  • Motor limit @2S LiPo / 6 cells NiMH = Onroad < 8T / Offroad < 11T
  • Motor limit @3S LiPo / 9 cells NiMH = Onroad < 11T / Offroad < 14T

touring car ATC2 4BL brushless rtr 4

Programmable functions:

  • Brake power  25% - 100%
  • Neutral brake  0% - 40%
  • Drive mode: forward-brake-backwards / forward-brake
  • Start mode (Punch): Level 1-4 (soft - aggressiv)
  • Low voltage cutt-off: off - 3.4V (default setting: 3.0V)
  • Technichal data : Measure (L/W/H) : 48.5 x 38 x 32 mm
  • Weight: 90g

Technichal data motor Thrust:
  • 3421 KV
  • 27.400 RPM/min @ 7.4 Volt
  • 4 Pole
  • Operating voltage: 4.8 – 11.1V
  • Motor size: 540
  • Motor length: 52.0 mm
  • Motor Ø : 36.0 mm
  • Shaft length: 14.5 mm
  • Shaft Ø: 3,17 mm

touring car ATC2 4BL brushless rtr 5

touring car ATC2 4BL brushless rtr 6

touring car ATC2 4BL brushless rtr 7

touring car ATC2 4BL brushless rtr 8

Technical data servo S40PH:
  • Size: Standard (Car)
  • Operating force: 4,0kg @ 4,8V
  • Speed: 0,16 Sec / 60° @ 4,8V
  • Gears: Nylon
  • Outdrive: 25T
  • Plug system: JR
  • Measure: (LxWxH) 40,2 mm x 20,4 mm x 39,8 mm
  • Voltage: 4.8V - 6.6V
  • Weight: 43g
  • Ball bearing

touring car ATC2 4BL brushless rtr 9

touring car ATC2 4BL brushless rtr 10

Technical data radio system:
  • 2-channel radio
  • 3-channel mini receiver
  • Reverse function
  • Dual rate and trimming adjustable
  • Battery case for 4 Mignon AA cells (not included)

Scope of delivery: 1 pcs. ATC2.4 Touring Car brushless RTR ( Incl. Motor, Speed controller, Steering servo - ready assembled) · Radio system · Manual

Required accessories: NiMH Racing pack or LiPo battery · Charger · 4 Mignon AA cells (radio)
